Maintenance CRT 36
4.12 Air Cleaner—CRT 36
The engine is equipped with a dual element air cleaner. Service air cleaner
frequently to prevent carburetor malfunction.
NOTICE: NEVER run engine without air cleaner. Severe engine damage will occur.
NEVER use gasoline or other types of low flash point solvents for cleaning the air
cleaner. A fire or explosion could result.
To service:
1. Remove air cleaner cover (a). Remove both elements (b, c) and inspect them
for holes or tears. Replace damaged elements.
2. Wash foam element (b) in solution of mild detergent and warm water. Rinse
thoroughly in clean water. Allow element to dry thoroughly.
Do not put oil on the foam element.
3. Tap paper element (c) lightly to remove excess dirt. Replace paper element if it
appears heavily soiled.
WARNING
wc_gr008243
b
c
a
