16 Technical data
50 100_0202_td_0016.fm
Designation Unit DPU5545
Hehap
DPU5545
Hec
DPU5545
Hech
Item number 5100009654 5100016950 5100009655
Centrifugal force kN 55.00 55.00 55.00
Oscillations Hz 69 69 69
1/min 4,150 4,150 4,150
Compaction performance* m
2
/h 1,170 980 980
Travel speed m/min 26.0 27.0 27.0
Gradeability % 57.7 57.7 57.7
Length (center pole in working
position)
mm 1,661 1,661 1,661
Width mm 750 604 604
Height mm 1,308 1,308 1,308
Operating weight kg 447.0 425.0 425.0
Ground clearance mm 790 – 914 790 – 914 790 – 914
Rated power ** kW 6.4 6.4 6.4
Nominal speed 1/min 2,850 2,850 2,850
Exciter oil volume l 0.75 0.75 0.75
Exciter oil type
75W-90 API GL-4
Hydraulic oil volume l
0,5 0,5 0,5
Type of hydraulic oil
MR 520
Storage temperature range °C -15 – +40 -15 – +40 -15 – +40
Operating temperature range °C -15 – +40 -15 – +40 -15 – +40
Sound pressure level
At location of operation L
pA
dB(A) 94 94 94
Standards EN 500-4
Sound power level L
wa
measured
guaranteed
dB(A)
107
108
107
108
107
108
Standards EN 500-4
Vibration total value a
hv
m/s
2
< 2.5< 2.5< 2.5
Standards
EN 500-4
Uncertainty of measurement of
the vibration total value a
hv
m/s
2
0.5 0.5 0.5
*
Depending on the soil properties.
**
Corresponds to the net installed power according to directive 2000/14/EC.
