5-16 BA E19 en* 1.0 * E19_10_500.fm
5 Operation
LED strip
The red LED strip D shows that the vehicle is in operating mode and that
could result in a danger situation in the work area.
5.6 Washer system
The switch is located on the switch panel on the right.
Damage to pump if the reservoir is empty.
► Do not actuate the washer system if the reservoir is empty.
► Check the level in the reservoir and add a cleaning solution (glass
cleaner) if necessary.
Damage to wiper if the front window is raised.
► Do not actuate the wipers if the front window is raised.
Washer system Operation
Wipers on Press switch A into position 1
Wipers off Press switch A into position 0
Spraying on Press switch A into position 2 and hold
Spraying off Release switch A
