4-28 BA E19 en* 1.0 * E19_10_400.fm
4 Putting into operation
4.3 Control and warning lights overview
Display element
The display element informs the operator about operating states, required
maintenance procedures and possible vehicle malfunctions.
It may take a few seconds before a selected function is displayed.
The indicator lights are tested when the starter is engaged and are
illuminated for a few seconds.
Fig. 110
8765
4
10 119 13 1412
16 1715 19 2018
1
2 3
