5-20 BA E19 en* 1.0 * E19_10_510.fm
5 Operation
ISO-/SAE-controls
The standard equipment of the vehicle includes ISO controls. SAE
controls are available as an option. This results in a different control lever
operation.
Accident hazard due to modified control mode!
Modified controls can cause incorrect operation, and serious injury or
death.
► Before starting work, check the selected control type.
The switch is located on the switch panel on the right.
Switching from ISO to SAE controls and vice versa:
Switching is only possible when the engine is running.
1. Raise the control lever base.
2. Press and hold ISO-/SAE button until the corresponding screen display
appears.
Function
Push but-
ton
Pop-up window
ISO controls
SAE controls
