Wacker Neuson ET42

BA E19 en* 1.0 * E19_10_510.fm 5-47
Operation 5
1. Start engine and lower the control lever base.
2. Move the attachment inward completely and lower it about 5–10 cm
(2–4 in) above the ground.
3. Pull lock A down.
4. Press switch B down.
➥ The symbol Hydraulic quickhitch enabled appears and the buzzer
sounds.
5. Press touch button C within 10 seconds.
➥ The quickhitch opens.
➥ Check pin D must be fully extended.
A
Fig. 195
B
C
Fig. 196
Fig. 197
Fig. 198
D
