Wacker Neuson ET42

BA E19 en* 1.0 * E19_10_600.fm 6-7
Transportation 6
Lifting eyes
The vehicle must only be raised using the lifting eyes indicated below.
Ensure that the lifting gear has the required lengths L1 and L2
Fig. 251
A
Position Quantity
A Dozer blade left and right 2
B Boom 2
Fig. 252
B
Fig. 253 (symbolic representation)
L2
L1
Length Dimensions
L1 3100 mm (10'-2'')
L2 4434 mm (14'-7'')
