Maintenance 7
Position Lubrication point
1
Interval Quantity
1 Boom Daily 2
2
Boom cylinder Daily 2
3
Shovel arm Daily 2
4
Stick cylinder Daily 2
5
Bucket cylinder Daily 2
6
Joint plate Daily 2
7
Hydraulic thumb Daily 5
8
Swiveling console Daily 2
9
Swiveling cylinder 50 o/h 2
10
Live ring (ball bearing) – see chapter “ Live ring (ball bearing)”
on page 7-12
50 o/h 1
11
Teeth of live ring – see chapter “ Teeth of live ring” on
page 7-13
50 o/h 1
12
Stabilizer blade Daily 4
13
Swiveling dozer blade Daily 7
1. Lubrication on the pins or directly on the cylinders
