BA E19 en* 1.0 * E19_10_710.fm 7-45
Maintenance 7
Adding hydraulic oil
Slipping/tripping hazard when adding hydraulic oil!
Can cause injury.
► Use a safety-oriented ladder to add hydraulic oil.
► Do not use vehicle parts or attachments as a climbing aid.
1. Open the reservoir ventilation B to release the pressure inside the
hydraulic oil reservoir.
2. Add hydraulic oil up to the corresponding mark.
3. Check the hydraulic oil level at the oil sight glass A.
4. Add if necessary and check again.
5. Screw down the reservoir ventilation B.
6. Close and lock the engine cover.
Use a suitable container to collect fluids and lubricants as they flow out
and dispose of them in an environmentally friendly manner.
