Technical data 9
Fuse Relays Protected circuits
F001 K005 Preheating
F002 K001 Heating, air conditioning
F003 K002 Vehicle electrical system, lighting, travel signal, horn, radio, window wiper
F004 K007 Starter
F005 -- Engine Controller
F006 -- Machine control unit
F007 -- Fuel-filling pump
F008 -- Blower, heating, air conditioning system
F010 -- Fuel pump
F011 -- Control unit CPU
F012 -- Control unit for ignition
F013 -- Travel signal
F014 -- Electronics
F015 -- Dozer blade, Jog dial, display element
F016 -- Pressure sensors
F017 -- Cab rocker switch
F018 -- Headlight, green rotating beacon
F019 -- Window wiper, interior light, horn, radio
F020 -- 12 V power outlet
F021 -- Electronics
F022 -- Ignition, theft protection
F023 -- Actuator for heating, air conditioning system, air conditioning compressor
F024 K012 Air conditioning system blower 1
F025 K013 Air conditioning system blower 2
F026 -- Radio, rotating beacon
-- K011 Air conditioning compressor
-- K042 Engine ECU
-- K076 Ignition electronics
-- K088 Fuel pump
-- K130 Horn
-- K146 Green rotating beacon
