Wacker Neuson HI 110HD D

wc_tx003764gb.fm
65
HI 110 / 200 / 300 Schematics
10.2 Electrical Schematic - HI 200 D
13
15
PE
7
3
14
12
1
5
2
11
10
1
4
J1
J4
J3
J2
BK
WH
BK
BK
WH
WH
WH
BK
BK
WH
WH
WH
RD
RD
RD
RD
YL
GY
BU
BK
BK
BK
BK
BR
BK
BU
WH
9
6
8
N
L
wc_gr012019
No. Description No. Description
1 Fuse 10 Room thermostat plug
2 High voltage transformer 11 Relay
3 Overheat thermostat 12 Control box
4 Solenoid valve 13 Heated fuel filter
5 CAD cell 14 Air pressure switch
6 Capacitor 15 Reset switch / lockout indicator
7 Fan motor 16 Resistance heater coil*
8 Electric pilot lamp 17 Nozzle line heater*
9 Control switch *Used on HD models only
