Setting up the Burner HI 400
56 ghi_tx001464gb.fm
6 Setting up the Burner
6.1 Removing the Access Cover
Requirements
Machine shut down and cooled
Machine properly positioned
Overview
Your machine is equipped with a removable access cover. The access cover must
be removed in order to maintain and repair certain machine components such as
the burner, electric motor, and fuel pump.
Procedure
Follow the procedure below to remove the access cover.
1. Shut down the machine and allow it to cool.
2. Disconnect the power cord from the power source.
3. Remove the four screws that fasten the access cover (g).
4. Remove the access cover and set it aside.
5. Perform the required maintenance.
6. When maintenance is complete, re-install the access cover and fasten it with
the screws.
CAUTION
Hot surface hazard. The machine surfaces may be hot.
f Allow the machine to cool for a minimum of ten minutes before touching it.
wc_gr007394
g
