HI 400HD D/ HD G Schematics
10.2 Components
No. Description No. Description
1 Line fuse 14 Pre-heated filter plug
2 Overheat thermostat 15 Summer/ winter switch
3 Solenoid valve 16 Overheat safety thermostat
4
CAD cell
17
Low fire / high fire power
switch
5 Capacitor 18 Preheated nozzle
6 Fan motor 19 Control board heater
7 Electric pilot lamp 20 Starter capacitor
8 Transformer H.V. 21 Solenoid valve
9 Room thermostat plug 22 Fan thermostat
10 Control box 23 Pressure switch heater
11 Air pressure switch 24 Heater nozzle relay
12 Heated fuel filter 25 Controller fuse
13 Burner motor — —
Wire Colors
BK Black RD Red YL Yellow OR Orange
GN Green TN Tan BR Brown PU Purple
BU Blue VIO Violet CL Clear SH Shield
PK Pink WH White GY Gray LB Lt. blue
