wc_td000736en.fm
49
LTS
Technical Data, 50 Hz
9
Technical
Data, 50 Hz
9.1
Floodlights
9.2
Mast
Item Number:
LT
S
7
K
LT
S
8
L
LT
S
8
K
LT
S
4
K
Floodlights
T
ype
Metal Halide
Metal
Halide
Metal Halide
LED
Power of each lamp
W
1,000
1,000
1,000
300
Floodlights installed
4
4
4
4
Illuminated area
m
2
(5 lux
min.)
4,200
4,200
4,200
4,500
Item Number:
LT
S
7
K
LT
S
8
L
LT
S
8
K
LT
S
4
K
Mast
Lifting meth
od
Manual
Maximum Height
m
8.5
Maximum Wind Speed
km/
h
80
Rotation
340°
Safety brake
Mechanical
48
50
Table of Contents
Default Chapter
3
Foreword
3
EC Declaration of Conformity
5
Table of Contents
7
1 Safety Information
11
Signal Words Used in this Manual
11
Machine Description and Intended Use
12
Safety Guidelines for Operating the Machine
13
Metal Halide Lamp Safety
16
Service Safety
16
Operator Safety While Using Internal Combustion Engines
18
Safety Guidelines for Lifting the Machine
19
Safety Guidelines for Towing the Machine
19
2 Labels
22
Label Locations
22
Label Meanings
22
3 Lifting and Transporting
24
Towing and Moving with Towing Vehicle
24
Handling and Transport with Crane
25
Handling and Transport with Forklift
26
Positioning and Uncoupling
27
4 Operation
28
Preparing the Machine for First Use
28
Positioning the Machine
28
Stabilizing the Unit
30
Directing and Using the Floodlights
31
Preliminary Check and Starting
33
Machine Components
34
Output Socket
36
Engine Start and Stop
37
Emergency Shutdown Procedure
38
Shut-Off
38
5 Maintenance
39
Routine Maintenance
39
Long-Term Storage
40
Disposal and Decommissioning
41
6 Engine Maintenance: KUBOTA Z482
42
7 Engine Maintenance: KOHLER
45
8 Engine Maintenance: KUBOTA D1005 / D1105
47
9 Technical Data, 50 Hz
49
Floodlights
49
Mast
49
Engine
50
Generator
50
Machine
51
Sound Measurements
51
Radiation Compliance
51
Dimensions
52
10 Technical Data, 60 Hz
53
Floodlights
53
Mast
53
Engine
54
Generator
54
Machine
55
Sound Measurements
55
Radiation Compliance
55
Dimensions
56
11 Schematics-LTS7K
58
Electrical Schematic Components
58
Electrical Schematic
59
Electrical Schematic
60
Electrical Schematic
61
Electrical Schematic
62
Electrical Schematic
63
12 Schematics-LTS8L
64
Electrical Schematic Components
64
Electrical Schematic
65
Electrical Schematic
66
Electrical Schematic
67
Electrical Schematic
68
Electrical Schematic
69
13 Schematics-LTS8K
70
Electrical Schematic Components
70
Electrical Schematic
71
Electrical Schematic
72
Electrical Schematic
73
Electrical Schematic
74
Electrical Schematic
75
14 Schematics-LTS4K
76
Electrical Schematic Components
76
Electrical Schematic
77
Electrical Schematic
78
Electrical Schematic
79
Electrical Schematic
80
Electrical Schematic
81
