Schematics—LTS8K LTS
13 Schematics—LTS8K
13.1 Electrical Schematic Components
Ref. Description Ref. Description
1 Battery charge alarm 12 Hour meter
2 High temperature switch 13 Emergency stop
3 Low oil pressure switch 14 Mains
4 IG battery charger 15 Lamp
5 Fuel pump/solenoid + 16 Basic Plus 66
6 Cranking 17 Ignitor
7 Preheating 18 12V battery
8 Battery + 19 Fuel pump
9 Battery - 20 Starter motor
10 Starter switch 21 Fuel solenoid
11 Lamp timer 22 Battery charger alternator
Wire Colors
BK Black RD Red YL Yellow OR Orange
GN Green TN Tan BR Brown PU Purple
BU Blue VIO Violet CL Clear SH Shield
PK Pink WH White GY Gray LB Lt. blue
