RCP Maintenance
39
Installing the cutting head
Sliding the cutting head
1. Place the cutting head on the machine so that when sliding on, the locating
pin on the cutting head engages into the hole on the machine.
2. Slide the cutting head to the stop.
Item Designation
1 Machine
2Bore
3 Locating pin
4 Cutting head
