Technical data RCP
12 Technical data
12.1 RCP-20/25 - 230
Designation Unit RCP-20 RCP-25
Item no. 0610201 0610203
Length x Width x Height mm (in) 385 x 180 x 240
(15.2 x 7.1 x 9.5)
405 x 170 x 250
(15.9 x 6.7 x 9.8)
Operating weight kg (lb) 13.7 (30.2) 13.9 (30.6)
Rated voltage V 230 1~
Rated frequency Hz 50
Rated power consumption W 1,400
Rated current consumption A 6.8
Class rating II
Protection class IP 20
Engine speed rpm 14,000
Operating temperature °C (°F) -20 to +50 (-4 to +122)
Hydraulic oil, specification HLP-ISO-46
Hydraulic oil, fill quantity l (gal) 0.6 (0.2)
Max. compressive force t 30 40
Opening/closing time of the tool s 5 5.5
Max. allowable tension strength
of the workpiece
N/mm
2
750
Max. allowable diameter work-
piece
mm (in) 20 (0.79) 25 (0.98)
Protective hood — —
Sound power level L
WA
in cutting
operation
dB(A) 102
Sound pressure level at
operator's station L
PA
in cutting
operation
dB(A) 94
