Accessories RCP
11.2.4 Operation
Installing the bending head
Before the bending head can be installed on the machine, the cutting head must
be removed, see 8.3 Installing and removing the cutting head (page 38).
Sliding the bending head
1. Place the bending head on the machine so that when sliding it on, the locat-
ing pin on the bending head engages into the bore on the machine.
2. Slide the bending head to the stop.
WARNING
Starting the machine!
Danger of injury with uncontrolled start up.
f Before all work on the machine and on accessories, remove the plug from
the plug receptacle.
Item Designation
1 Machine
2Bore
3 Locating pin
4 Bending head
