RCP Accessories
47
Fastening the bending head
1. Put the collar on.
2. Turn and tighten the fastening screw on the collar.
3. Tighten the die with the fastening screw, spring washer and nut onto the
thrust bolt.
Item Designation
1 Collar
2Nut
3 Die
4 Fastening screw
5 Thrust bolt
6 Fastening screw
