Rocker switch for "electric power outlet on the
mast" (option)
The rocker switch 39 is located in Rocker switch panel 1.
Pressing the rocker switch switches the power supply on
and off for the electric power outlet on the mast.
➥ Electric power outlet on the loader unit on
page 5-84
"Hydraulic lock for attachments" rocker switch
(option)
The rocker switch 40 is located in Rocker switch panel 1.
Pressing rocker switch activates the auxiliary hydraulics
for attachments for unlocking the hydraulic lock. For more
information on hydraulic lock operation
➥
Re-equipping attachments on page 5-46
