5-36
BA TH412 * 06/2017 * 4512_5-9_Arbeitshydraulik_en.fm
5 Operation
Disabling the overload cutoff
Accident hazard due to overload and sudden
movements!
Overload and sudden movements can cause accidents
and injury.
► Pay attention to the load diagram and payloads of the
machine.
► Operate the control levers carefully.
In order to be able to position loads in the overload range,
the overload protection can be temporarily bypassed by
pressing the rocker switch 38 in the Rocker switch panel 1
and the control lever 4.
If the overload protection has been triggered, proceed as
follows.
1. Move the rocker switch 38 to position II.
2. With the switch pressed, reduce the load with the
control lever (for example set down the load).
The overload protection is only disabled as long as the
switch is pressed, however for a maximum 30 seconds.
