Carburetor Replacement WM 80 Repair
68 wc_tx000522gb.fm
Installation
Perform the procedure below to install the carburetor
6.1.1 Assemble the adapter (j), lower gasket (l), flange (k), and upper
gasket
(o) to the carburetor (i). Note: The gaskets are not
interchangeable.
6.1.2 Connect the oil hose (h), and the fuel hose (n), to the carburetor.
6.1.3 Install the carburetor assembly to the engine.
