WM 80 Repair Carburetor Overhaul
wc_tx000522gb.fm 77
7.2 Walbro Carburetor Components (auto-release choke models)
Ref Description Ref Description
1 Screw 21 Screw
2 Cover 22 Screw
3 Gasket 23 Cover
4 Diaphragm 24 Bulb
5 Screen 25 Valve
6 Washer 26 Air purge body assembly
7 Spring 27 Diaphragm
8 Choke shaft 28 Gasket
9 Spacer 29 Nozzle
10 Throttle lever 30 Spring
11 Screw 31 Needle
12 Swivel 32 Needle valve
13 Retaining ring 33 Idle speed screw
14 Inlet valve 34 Spring
15 Lever 35 Throttle shaft
16 Pin 36 Choke lever
17 Screw 37 Sleeve
18 Spring 38 Screw
19 Plug 39 Choke valve
20 Throttle valve — —
