WM 80 Repair Carburetor Replacement
wc_tx000522gb.fm 75
6.6 Bing
See Graphic: wc_gr002900
6.6.1 Turn off the fuel valve at the tank and disconnect the spark plug lead
wire.
6.6.2 Remove the air filter pipe (loosen both clamps).
6.6.3 Disconnect the throttle cable.
6.6.4 Loosen the clamp which secures the carburetor to the adapter and
slide the carburetor off the adapter.
6.6.5 Protect the cylinder from dirt by cranking the engine until the piston is
covering the intake port.
wc_gr002899
wc_gr002900
