WACOM Intuos S User Manual

Assign settings to Radial Menus and Screen Keys
After you create a Radial Menu or Screen Key panel, you need to assign settings to the buttons and slices. You can change the
settings at any time if you decide that you want different settings.
1. In Wacom Tablet Properties on the On-Screen Controls tab, select the name of the On-Screen Control in the Panels list.
A drop-down menu for each button in your On-Screen Control displays under Key Assignment.
2. Select the setting that you want to assign to each button from the drop-down menus.
You must assign a setting to at least one button. For any buttons that you do not want to use, select Disabled.
If you select Keystroke, you are prompted to select a keystroke or create a keystroke combination.
The above screenshot is for descriptive purposes; it may not match your screen.
3. Change any of the optional features:
To change the order of the settings, click and drag it to a new position.
If you want the setting to repeat when you click and hold the On-Screen Control button, select Repeat.
Important: Assign your On-Screen Control to a customizable component, like an ExpressKey or pen button, so that you
can open it when you want to use it.
User's Manual
37
37

WACOM Intuos S Specifications

General

Resolution	2540 lpi
Working area	152 x 95 mm
Device interface	USB/Bluetooth
Tablet input type	Pen
Connectivity technology	Wired & Wireless
Mouse included	No
Aspect ratio	-
Display diagonal	7 \
Product color	Black
Cables included	USB
Battery life (max)	15 h
Interface	USB-A
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	8.8 mm
Width	200 mm
Height	160 mm
Pen weight	11.2 g
Tablet weight	250 g
