WACOM Intuos S User Manual

Assign settings to Keypads
After you create a Keypad, you can change the settings assigned to the buttons so that the Keypad includes the settings you
want.
1. In Wacom Tablet Properties on the On-Screen Controls tab, select the name of the Keypad in the Panels list.
An image of a Keypad appears under Key Assignment with default settings assigned to it.
2. Click a Keypad button that you want to change.
3. Select the setting that you want to assign from the Assignment drop-down above the Keypad.
To assign numbers, select Keyboard > Keystroke. When you select Keystroke, you are prompted to select a
keystroke or create a keystroke combination.
If you want the setting to repeat when you press and hold the Keypad button, select Repeat.
You must assign a setting to at least one button. For any buttons that you do not want to use, select Disabled.
Assign your On-Screen Control to a customizable component, like an ExpressKey or pen button, so that you can open it
when you want to use it.
User's Manual
38
38

WACOM Intuos S Specifications

General

Resolution	2540 lpi
Working area	152 x 95 mm
Device interface	USB/Bluetooth
Tablet input type	Pen
Connectivity technology	Wired & Wireless
Mouse included	No
Aspect ratio	-
Display diagonal	7 \
Product color	Black
Cables included	USB
Battery life (max)	15 h
Interface	USB-A
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	8.8 mm
Width	200 mm
Height	160 mm
Pen weight	11.2 g
Tablet weight	250 g
