PORTION OF TABLET AREA
To define the tablet area that will be mapped to the screen area, in the MAPPING tab choose a TABLET AREA
option.
F
ULL The entire active area of the tablet is mapped. This is the default setting.
P
ORTION... In the dialog box that appears, choose a method for defining a portion of the
tablet:
• Drag corners of the foreground graphic
to select the tablet area that will be
mapped to your selected screen area.
• Select the C
LICK TO DEFINE TABLET AREA
button and use your tool on the tablet
to select the tablet area. Be sure to
follow any M
ESSAGE prompts.
• Enter coordinate values.
