EN
17
MAINTENANCE
REPLACING THE FILTERS
tention
Before every use, you should inspect the air lters in the
turbine to see if it is excessively dirty. If it is dirty, follow
these steps to replace it.
Never operate your unit without the air lters. Dirt could
be sucked in and interfere with the function of the unit.
1. Press the tabs on each side of the turbine to remove the lter covers.
Remove the dirty lters from the turbine and replace with new
ones. The smooth side of the air lter must be placed toward the
turbine.
Secure the covers back onto the turbine.
CLEANING THE AIR VALVE TUBE
If spray material ever enters the air valve tube, follow
the steps below.
The air valve tube for both the iSpray nozzle and the
Gravity Feed nozzle operate in the same manner.
1. iSpray - Pull the air tube (a) at the top from the nozzle, and. Unscrew
the valve cover (b).
Gravity Feed - Pull the air tube (a1) from the nozzle and the top of
the container (a2). Twist the two halves of the valve seal housing to
access the valve seal (c).
Remove the valve seal (c). Clean all the parts carefully. Make sure to
remove any material from valve seal housing area (d).
tention
The air tube and valve seal (c) are only solvent-resistant
to a limited extent. Do not immerse in solvent, only wipe.
2. Place the valve seal (c) in the valve cover (b) with the pin facing into
the tube. Installing the valve seal into the valve cover will be much
easier if the valve cover is inverted.
3. Turn the nozzle upside down and screw on the valve cover (with
valve seal inside) from underneath. Turning the nozzle upside
down will prevent the valve seal from falling out of the valve cover
during reinstallation.
4. iSpray - Place the air tube on the valve cover and on the nipple at
the nozzle.
Gravity Feed - Reattach the air tube to the nozzle and to the top of
the container.
1
(a)
(b)
(c)
(d)
(d)
(c)
(b)
(a1)
(a2)
2
(c)
(b)
3
4
1
iSPRAY GRAVITY FEED
