13
VM 500
OPERATING MANUAL
EDITION 03/2012 PART NUMBER DOC 2318724
4 DESCRIPTION
4.1 FIELDS OF APPLICATION, USING IN ACCORDANCE WITH THE INSTRUCTIONS
WAGNER‘s electrostatic control unit VM 500 controls the high voltage supply to the spray
guns used to apply liquid coating media GM 5000EAC and GM 5000EA.
The VM 500 may only be operated together with the above-mentioned hand spray guns.
If the control unit is operated in combination with devices other than the above-
mentioned spray guns, the SIRA and FM authorizations (type approvals) cease to apply.
As a result of the „gas-proof“ type of explosion protection, the control unit is suitable for
use in ex-zone 2. This is guaranteed providing all sealed elements in the control unit are
available and undamaged. During operation, all electric connections in the control unit
and relevant plug connectors or shut-off devices have to be tightly sealed.
4.2 SCOPE OF DELIVERY
Quantity Part No. Description
1 2310478 VM 500 control unit
The standard equipment includes:
Quantity Part No. Description
1 241270 Mains cable with Stak200; 3 m; 9.8 ft
1 130215 Earthing cable 10 m; 32.8 ft
2 9951117 Delay-action fuses 1.0 AT
1 2310487 ES 5000 Hand Declaration of conformity
1 2310485 VM 500 Operating manual German
1 see 1.1 Operating manual in the local language
The delivery note shows the exact scope of delivery.
