22
VM 500
B_03423
VM 500
2
B_03423
VM 500
1
OPERATING MANUAL
EDITION 03/2012 PART NUMBER DOC 2318724
6 START-UP AND OPERATION
DANGER
High voltage field!
Danger to life from malfunctioning heart pacemakers
Ensure that persons with heart pacemakers:
Do not work with the electrostatic spray gun.
Remain outside the area of the electrostatic spray gun/work -
piece.
SIHI_0049_GB
➞ Observe safety instructions in chapter 2.
6.1 STARTING UP AND SPRAYING
1. Set main power switch to position I.
For approx. 1 second all LED‘s light up
-> Display test.
2. If the operating signal light (2) is
green, the control unit is ready to be
operated.
3. When the spray gun trigger is pulled,
high-voltage is switched on. This is
indicated by the high-voltage LED (1).
