29
VM 500
OPERATING MANUAL
EDITION 03/2012 PART NUMBER DOC 2318724
Item Qty Part No. Description
1 1 2310478 VM 500 control unit
4 1 9950330 Safety catch for connector sockets
5 2 9903306 Oval head screw, phillips screwdriver, form H
6 1 9910102 Hexagon nut
7 1 9910522 High knurled nut
8 1 9920118 Washer
9 1 9922017 Lock washer outside toothed
10 2 9903311 Oval head screw, phillips screwdriver, form H
11 1 241323 Cover, white
12 1 2317597 Print compl. VM 500 control
13 3 263400 Distance bush
14 3 9922011 Lock washer outside toothed
15 3 9910103 Hexagon nut
16 5 2312348 Hexagon lock nut
17 4 9922011 Lock washer outside toothed
18 4 9903312 Oval head screw, phillips screwdriver, form H
19 8 2306405 Countersunk screw, phillips screwdriver, form Z
20 1 2307315 Seal
21 1 2307309 Cover
22 4 9990839 Buffer
23 1 9955176 Power pack
24 5 2309112 Spacer
26 1 2317598 Print compl. VM 500 display
29 1 9953536 2-pin rocker switch
30 1 9952587 Equipment plug
31 1 9955021 Fuse holder
32 2 9951117 Delay-action fuse 1.0 AT
33 1 9971519 Rubber seal
34 1 9955601 Speedily fuse 2.5 A
35 1 2325264 Seal
