Operating manual Piston pump IceBreaker 40-200 ccm (Finishing)
14 Spare Parts
104 Order number 2333538 | Edition 03/2021
Pos K Stk Order no. Designation
PE / TG PE/L PE/T
4 1 2327888 Inlet housing 150
5 ♦ 1 368555 Piston
6 1 368506 Valve screw
7 ♦ ⋆ 1 368507 Ball guide, inlet
8 1 368551 Connecting flange
9 ♦ 1 368509 Valve seat, inlet
10 ♦ 1 368510 Valve seat, outlet
11 1 368561 Snap ring flange
12 2 368512 Snap ring half
13 1 368513 Securing ring
16 1 368516 Support ring
17 1 367519 Pressure ring
18 1 368518 Support ring
19 1 368519 Pressure ring
100 ♦ 1 367991 / / Packing PE/TG, complete (small)
101 ♦ 1 / / 367992 Packing PE/T, complete (small)
102 ♦ 1 / 367993 / Packing PE/L, complete (small)
20 ♦ ⋆ 2 367522 / / Sealing collar TG (small)
♦ ⋆ 2 / / 367900 Sealing collar T (small)
♦ 2 / 367922 / Sealing collar L (small)
21 ♦ ⋆ 3 367523 Sealing collar PE (small)
103 ♦ 1 368991 / / Packing PE/TG, complete (large)
104 ♦ 1 / / 368992 Packing PE/T, complete (large)
105 ♦ 1 / 368993 / Packing PE/L, complete (large)
22 ♦ ⋆ 2 368522 / / Sealing collar TG (large)
♦ ⋆ 2 / / 368900 Sealing collar T (large)
♦ 2 / 368922 / Sealing collar L (large)
23 ♦ ⋆ 3 368523 Sealing collar PE (large)
25 ♦ ⋆ 2 368525 O-ring
27 ♦ ⋆ 1 368527 O-ring
28 ♦ ⋆ 1 368528 O-ring
40 ♦ ⋆ 1 9998670 Wave spring (small)
41 ♦ ⋆ 1 9998671 Wave spring (large)
42 ♦ ⋆ 1 9943082 Ball (large)
43 ♦ ⋆ 1 9941512 Ball (small)
44 ♦ ⋆ 1 9974092 O-ring
46 ♦ ⋆ 1 9974107 O-ring
50 3 9907142 Hexagon screw
51 3 9925011 Washer
57 ● 1 369926 Ball guide for high-viscosity products
