WAGNER Leopard 35-150 - High-Pressure Filter, 530 Bar

Operating manual Piston pump IceBreaker 40-200 ccm (Finishing)
14 Spare Parts
Order number 2333538 | Edition 03/2021 113
14.12 HIGH-PRESSURE FILTER, 530 BAR
90 Nm; 66 lbft
140 Nm
103 lbft
12
21
11
10
1
4
7
13
20
33
2
3
5
B_03934
23
34
36
35
36
34
34
20
34
A
B
C
D
53 MPa
530 bar
7687 psi
A Tighten pos. 3 by hand C Stainless steel
B Identification of the filter D Carbon steel
