Operating manual Piston pump IceBreaker 40-200 ccm (Finishing)
14 Spare Parts
Order number 2333538 | Edition 03/2021 107
Pos K Stk Order no. Designation
PE / TG PE/T
6 1 2336692 Valve screw
7 1 2386282 Ball guide, inlet
8 1 2336661 Connecting flange
9 ♦ 1 369509 Valve seat, inlet
10 ♦ 1 2336695 Valve seat, outlet
11 1 2336689 Snap ring flange
12 2 2336785 Snap ring half
13 1 2336690 Securing ring
14 ♦ ⋆ 1 2386283 Pressure spring
16 1 2336670 Support ring
17 1 2336680 Pressure ring
18 1 2336686 Support ring
19 1 2336694 Pressure ring
100 ♦ 1 2341473 / Packing PE/TG, complete (small)
101 ♦ 1 / 2345985 Packing PE/T, complete (small)
20 ♦ ⋆ 2 2336679 / Sealing collar TG (small)
♦ ⋆ 2 / 2343776 Sealing collar T (small)
21 ♦ ⋆ 3 2336674 Sealing collar PE (small)
103 ♦ 1 2341474 / Packing PE/TG, complete (large)
104 ♦ 1 / 2345986 Packing PE/T, complete (large)
22 ♦ ⋆ 2 2336688 / Sealing collar TG (large)
♦ ⋆ 2 / 2343775 Sealing collar T (large)
23 ♦ ⋆ 3 2336687 Sealing collar PE (large)
25 ♦ ⋆ 1 369527 O-ring
26 ♦ ⋆ 1 2336684 O-ring
27 ♦ ⋆ 1 9974194 O-ring
28 ♦ ⋆ 1 2338256 O-ring
40 ♦ ⋆ 1 2338091 Wave spring (small)
41 ♦ ⋆ 1 2338092 Wave spring (large)
42 ♦ ⋆ 1 9943086 Ball (large)
43 ♦ ⋆ 1 9941513 Ball (small)
44 ♦ ⋆ 1 9974132 O-ring
46 ♦ ⋆ 1 2336683 O-ring
50 3 9907142 Hexagon screw
51 3 9925011 Washer
52 1 2328465 Fitting, DF-MM-R1 1/2"-M36x2-SSt
53 ♦ 1 2329898 Sealing sleeve
60 1 9998808 Mobilux® EP 2 grease
61 1 9992609 Anti-seize paste
62 1 9992616 Molykote® DX grease
