Operating manual Piston pump IceBreaker 40-200 ccm (Finishing)
14 Spare Parts
Order number 2333538 | Edition 03/2021 115
Pos K Stk Order no. Designation
AirCoat regu-
lator
AirCoat filter
regulator
1 1 2328611 / AirCoat regulator set
2 1 / 2382997 AirCoat filter regulator set
3 1 2309972 / Pressure regulator valve, LR-1/4-D-O-I-Mini
4 1 / 2331950 Filter control valve (manual drain)
/ 2360259 Option: filter pan (automatic drain)
5 1 9998677 Pressure gauge, 0-10 bar, RF40 (d40)
6 1 9974166 / O-ring
7 1 2325527 / Holding plate
8 1 9906021 / Hexagon socket head cap screw
9 1 9900320 / Hexagon socket head cap screw
10 1 9994627 / Double fitting, R1/4-R1/4
11 1 9971313 / O-ring
12 1 9992831 / Loctite® 542
13 1 9992616 / Molykote® DX grease
14 1 9998808 / Mobilux® EP 2 grease
15 1 / 9992528 Loctite® 270
16 1 / 2366466 Contact plate
17 1 / 2389277 Fitting, EF-MM-G1/4-R1/4-530 bar
18 2 / 9900152 Hexagon screw without shaft
19 3 / 9920104 Washer
20 1 / 9998719 Detachable double fitting
= wearing parts
