Operating manual Piston pump IceBreaker 40-200 ccm (Finishing)
5 Description
Order number 2333538 | Edition 03/2021 27
Pos Wildcat 10-70
mm; inch
Wildcat 18-40
mm; inch
Puma 28-40
mm; inch
Puma 21-110
mm; inch
I ⌀ 25; ⌀ 1
J M6
K M36×2
L1 M24×1.5
L2 G3/8"
M G1/2"
N G1/4"
O 106; 4.2
P 96.5; 3.8
Q ⌀ 9; ⌀ 0.35
R ⌀ 7; ⌀ 0.28
S 149; 5.9
T 55; 2.2
5.5.6 Technical Data for Leopard
Description Units Leopard
35-70
Leopard
48-110
Leopard
35-150
Leopard
26-200
Pump ratio 35:1 48:1 35:1 26:1
Flow volume per double stroke (DS) cm³ / cc 70 110 150 200
Maximum operating pressure MPa
bar
psi
25
250
3626
37
370
5366
27
270
3916
20
200
2900
Maximum possible strokes in operation DS/min 60
Maximum recommended strokes per
minute in continuous operation
DS/min 40
Minimum/maximum air inlet pressure MPa
bar
psi
0.25 – 0.71
2.5 – 7.1
36 – 103
0.25 – 0.77
2.5 – 7.7
36 – 112
Compressed air quality: free from oil
and water
Quality standard 7.5.4 according to ISO 8573.1, 2010
7: Particle concentration 5–10mg/m³
5: Humidity: pressure dew point ≤ 7 °C
4: Oil content ≤5mg/m³
Air inlet diameter (internal thread) inch G1/2"
Minimum diameter of the compressed
air supply line
mm; inch 13; 0.51
Air consumption at 0.6 MPa; 6 bar; 87
psi per double stroke
nl; scf 18.6; 0.66 37.3; 1.32
Air motor piston diameter mm; inch 150; 6
Air motor piston stroke mm; inch 75; 3 150; 6
Sound pressure level at maximum per-
missible air pressure*
dB(A) 77 78 80
