Operating manual Piston pump IceBreaker 40-200 ccm (Finishing)
13 Accessories
74 Order number 2333538 | Edition 03/2021
Pos K Order no. Designation
Leopard
35-70 **
Leopard
35-150
Leopard
48-110
Leopard
26-200
A 2329479 2329484 2329490 2417044 Piston pump PE/TG
A 2329481 2329486 2329493 2417043 Piston pump PE/T
A -- -- 2329495 / Piston pump PE/L
A 2366702 / / / Piston pump PE/T TC 1.4404 **
1 9992504 Separating agent 250 ml; 250 cc
2 236219 Grounding cable 3 m; 9.8 ft
3 9907133 Lifting eye bolt
4 2328611 -- AirCoat regulator set (see chapterAircoat Regulator
and Aircoat Filter Regulator [8114])
5 2382997 -- AirCoat filter regulator set (see chapterAircoat Regu-
lator and Aircoat Filter Regulator [8114])
19 9985619 Plug-in fitting with hose fitting DN13
20 9998813 Plug-in fitting with quick-release coupling DN13
21 9998812 Quick release coupling with hose fitting DN 13
24 2334957 Regulator lock
25 2335815 -- Ball valve DN7-PN10-G1/4-R1/4-CB
26 9992831 -- Loctite® 542, 50ml; 50cc
Product output up to 27MPa; 270bar; 3916psi (**)
27 2329024 -- 2329024 HP filter, DN10-PN270-SSt, complete
For details and filter cartridges: see chapter High-
pressure Filter, 270 Bar [8111]
28 2329023 -- 2329023 Relief combination, complete
For details, see chapterRelief Combination, 270 Bar
[8109]
29 2324558 -- 2324558 Inline filter, DN6-PN270-G1/4"-SSt
For details and filter insert: see chapter Straight In-
line Filter, 270 bar [8109]
30 2329026 -- 2329026 Inline-Filter, HL DN6-PN530-G1/4"-SSt
For details and filter insert: see chapterAngled Inline
Filter, 530 Bar [8110]
31 2332619 -- 2332619 Adapter G1/4"-NPS1/4"
Product output up to 53MPa; 530bar; 7687psi (**)
50 2329025 HP filter DN12-PN530-SSt with stainless steel ball
valve
For details and filter cartridges: see chapterHigh-
pressure Filter, 530 Bar [8113]
51 -- 2335334 -- HP filter DN12-PN530-SSt with carbon steel ball valve
For details and filter cartridges: see chapterHigh-
pressure Filter, 530 Bar [8113]
52 2332621 Adapter G3/8"-NPS1/4"
53 2332620 Adapter G3/8"-NPS3/8"
54 2331752 Return tube DN6-G1/4"-100mm-PE
55 2331017 Circulation hose DN6-G1/4"-1.8m-PA
