Operating manual Piston pump IceBreaker 40-200 ccm (Finishing)
14 Spare Parts
96 Order number 2333538 | Edition 03/2021
Pos K Stk Order no. Designation
PE / TG PE/T
4 1 2322467 Inlet housing 40
5 ♦ 1 367505 Piston
6 1 367506 Valve screw
7 ♦ ⋆ 1 367507 Ball guide, inlet
8 1 367501 Connecting flange
9 ♦ 1 367509 Valve seat, inlet
10 ♦ 1 367510 Valve seat, outlet
11 1 367511 Snap ring flange
12 2 367512 Snap ring half
13 1 367513 Securing ring
16 1 367516 Support ring
17 1 367517 Pressure ring
18 1 367518 Support ring
19 1 367519 Pressure ring
100 ♦ 1 115805 / Packing PE/TG, complete (small)
101 ♦ 1 / 123219 Packing PE/T, complete (small)
20 ♦ ⋆ 2 123398 / Sealing collar TG (small)
20 ♦ ⋆ 2 / 123426 Sealing collar T (small)
21 ♦ ⋆ 3 123427 Sealing collar PE (small)
103 ♦ 1 367991 / Packing PE/TG, complete (large)
104 ♦ 1 / 367992 Packing PE/T, complete (large)
22 ♦ ⋆ 2 367522 / Sealing collar TG (large)
22 ♦ ⋆ 2 / 367900 Sealing collar T (large)
23 ♦ ⋆ 3 367523 Sealing collar PE (large)
25 ♦ ⋆ 2 367525 O-ring
27 ♦ ⋆ 1 367527 O-ring
28 ♦ ⋆ 1 367528 O-ring
40 ♦ ⋆ 1 9998669 Wave spring (small)
41 ♦ ⋆ 1 9998670 Wave spring (large)
42 ♦ ⋆ 1 9941513 Ball (large)
43 ♦ ⋆ 1 9941518 Ball (small)
44 ♦ ⋆ 1 9974094 O-ring
46 ♦ ⋆ 1 9974106 O-ring
50 3 9907124 Hexagon screw
60 1 9998808 Mobilux® EP 2 grease
61 1 9992609 Anti-seize paste tube
62 1 9992616 Molykote® DX grease
70 1 2329922 Fitting SF-MM-G3/8"-M24x1.5-PN530-SSt
71 1 2329898 Sealing sleeve
