Operating manual Piston pump IceBreaker 40-200 ccm (Finishing)
14 Spare Parts
98 Order number 2333538 | Edition 03/2021
* Notice regarding pos. 111: Stainless steel valve seat set 70, consisting of: pos. 28, 10, 27 and
9, but in stainless steel version.
Order no.
PE / TG PE/L PE/T PE/T TC 1.4401
1 1 2329645 - 2329647 2366710 Fluid section
2 1 368502 2370141 Pipe
3 1 368503 2370139 Cylinder
4 1 2322465 2370138 Inlet housing 70
5 ♦ 1 368505 2370129 Piston
6 1 368506 2370137 Valve screw
7 ♦ ⋆ 1 368507 2338788 Ball guide, inlet
8 1 368501 Connecting flange
9 ♦ 1 368509 Valve seat, inlet
10 ♦ 1 368510 Valve seat, outlet
11 1 368511 Snap ring flange
12 2 368512 Snap ring half
13 1 368513 Securing ring
16 1 368516 2370142 Support ring
17 1 367519 2366649 Pressure ring
18 1 368518 2370140 Support ring
19 1 368519 2366647 Pressure ring
100 ♦ 1 367991 / / -- Packing PE/TG, complete
(small)
101 ♦ 1 / / 367992 Packing PE/T, complete
(small)
102 ♦ 1 / 367993 / -- Packing PE/L, complete
(small)
20 ♦ ⋆ 2 367522 / / -- Sealing collar TG (small)
♦ ⋆ 2 / / 367900 Sealing collar T (small)
♦ 2 / 367922 / -- Sealing collar L (small)
21 ♦ ⋆ 3 367523 -- Sealing collar PE (small)
103 ♦ 1 368991 / / -- Packing PE/TG, complete
(large)
104 ♦ 1 / / 368992 Packing PE/T, complete
(large)
105 ♦ 1 / 368993 / -- Packing PE/L, complete
(large)
22 ♦ ⋆ 2 368522 / / -- Sealing collar TG (large)
♦ ⋆ 2 / / 368900 Sealing collar T (large)
♦ 2 / 368922 / -- Sealing collar L (large)
23 ♦ ⋆ 3 368523 -- Sealing collar PE (large)
25 ♦ ⋆ 2 368525 O-ring
27 ♦ ⋆ 1 368527 O-ring
28 ♦ ⋆ 1 368528 O-ring
