Operating manual Powder Cup Gun PEM-X1 CG
12 Accessories
50 Order number 2326960 | Edition 10/2022
12.1.4.1 Flat Jet Nozzles System
Order no. K Designation
2323401
♦
Nozzle insert, X1 VL F (yellow)
P_04993
Can be combined with:
2324147 ♦ Flat jet nozzle, X1 VL ET
P_04995
♦ = Wearing parts
12.1.4.2 Round Jet Nozzles System
Order no. K Designation
2323461
♦
Nozzle insert, X1 VL R (yellow)
P_04992
Can be combined with:
2321981 ♦ Deflector cone, D18, complete
P_01665
2321980 ♦ Deflector cone, D25, complete
P_01666
2321171 ♦ Deflector cone, D34, complete
P_01667
Set:
2324148 ♦ Round jet nozzle set X1 VL (comprising nozzle insert
and the three deflector cones)
♦ = Wearing parts
