descriptiOn Of unit
PS 3.29 / 3.31
3.4 LEGEND FOR EXPLANATORY DIAGRAM
PROSPRAY 3.29 / 3.31
3.5 EXPLANATORY DIAGRAM PS 3.29 / 3.31
1. Spray gun
2. High-pressure hose
3. Oil cup for EasyGlide (EasyGlide
prevents increased wear of the
packings)
4. Oil level gauge
5. Pail hook
6. Oil button
7. Suction tube
8. Return hose
9. Cart
10. Relief valve
Lever position vertical – PRIME ( k circulation)
Lever position horizontal – SPRAY ( p)
11. Digital Electronic Spray Control (DESC)
12. Control panel indicators
13. Pressure control knob
14. ON/OFF switch
