58
Super Finish 23 PLUS
GB
SPARE PARTS AND ACCESSORIES
36 9905 113 Oval head screw 5x10
37 9950 242 Seal
38 2342 535 Label
39 2343 666 Pressure gauge
40 9970 218 Sealing ring
41 2341 465 Label (right)
ITEM ORDER-NO DESIGNATION
1 0340 339 Inlet
2 2334 383 Inlet valve trigger housing
3 0341 336 Clasp
4 9971 486 O-ring
5 0341 316 Wiper
6 2337 033 Inlet valve trigger (incl. pos. 4, 5)
7 0341 331 Sealing ring
8 0344 700 Inlet valve (incl. pos.7 (2x))
9 2334 402 Inlet valve complete. (pos. 1,2,3,6,8)
10 0421 328 Oval head screw 3, 17x20
11 2337 138 O-ring 31.4 x 3.55
12 9952 685 Cable threaded joint
13 0261 352 Mains cable
H07-RNF 3x 1.5mm², 6m long
14 0344 336 Double socket NPS 1/4“
15 2334 038 Cover
16 2334 044 Cover (right)
17 2315 382 Oval head screw M4x10
18 2339 570 Label SF 23 PLUS
19 0341 347 Sealing ring
20 0341 327 Outlet valve seat
21 9941 501 Ball 10
22 0253 405 Spring support ring
23 0341 326 Pressure spring
24 0341 328 Clasp
25 9971 470 O-ring 20x2
0341 702 Outlet valve, service set (pos. 19-25)
26 2342 946 Outlet valve complete (incl. pos.19-25)
27 2334 046 Connecting plate
28 2334 042 Cover (left)
29 2337 557 Fan cover
30 9902 225 Oval head screw 3.5x9.5
31 2341 466 Label (left)
32 9903 348 Self drilling screw
33 2337 484 Connecting plate
34 2342 501
Multi-function switch
35 9950 241 Socket
11.2 SPARE PARTS LIST SF 23 PLUS
