Walker Edison BQSPIN - Step 12: Connect Brackets to Bottom Rail; Step 13: Attach Support Beams to Top Rail

P. 10
Step 12
Step 13
5
5
7
6
13
13
B
B
B
B
2
Ø3,5x30mm
D
2
Ø7x50mm
J
1
D+J
D+J
D
J
Connect parts 5 to part 7. Note the drawing for location of pocket hole. Secure parts 5
to part 7 with the screw (B) using a Phillips head screwdriver (not included).
Attach parts 13 to part 6 with the bold D using a hex key (J).
