Walker Edison BQSPIN - Step 14: Fit Headboard Spindle; Step 15: Connect Spindles to Top Rail

P. 11
Step 14
Step 15
D
2
Ø7x50mm
J
1
D+J
D+J
B
14
Ø3,5x30mm
B
D
J
13
13
5
5
7
6
1
1
1
1
1
1
1
1
1
1
1
1
1
1
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
1
1
6
Start at one end of the headboard. Fit large spindle
13 into part 5 and secure with screw (D) using a
hex key (J).
Insert the Spindle 1 underneath and the Screw (B)
to connect to Part 6 using a Phillips head screwdriver (not included).
