Walker Edison BQSPIN - Step 20: Join Bottom Rail; Step 21: Assembly Complete

P. 14
Step 20
Step 21
250
lbs
250
lbs
Assembly Complete!
M
6
Ø1/4x40mm
N
6
Join the part 7 to parts 29 and 5 with screw (M) and union screw
(N) using hex key (J)
N+J
M+J
N+J
N+J
N+J
N+J
N+J
M+J
M+J
M+J
M+J
M+J
M
N
J
J
M
J
N
J
7
5
21
29
