Walker Edison BQSPIN - Step 8: Secure Feet; Step 9: Attach Metal Connector Plates

P. 8
Step 8
Step 9
B
8
Ø3,5x30mm
Attach the metal connector plate (Q) to the 2 corners of
the bed with screw (P), using a Phillips head screwdriver
(not included).
P
8
Ø4x16mm
Q
2
B
Q
B
B
B
B
B
B
B
B
B
P
P
P
P
Q
P
P
P
P
P
P
P
P
Q
Secure feet to Right side rail and Left side rail,
with screw (B) using a Phillips head screwdriver (not included).
15
15
15
15
28
28
21
20
