SAFETY, CONTROL, AND INSTRUCTION DECALS
Safety, Control, and Instruction Decals are installed on the machine;
if any are missing, illegible, or damaged, a replacement should be ordered and installed before
putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
Location: Flex Coupler Guard in Front of Engine
Part Number: 8600-2
8600-2
1.
1. Warning – entanglement and cutting/dismem-
berment hazards
• Keep away from rotating shafts, belts, and
other components.
Location: Right Fender
Part Number: 2802-2
Location: Underside of Rear Body
Part Number: 2107-4
1.
2.
1. Ground drive belt routing
2. PTO clutch belt routing
TIGHTEN UNTIL CONTACT WITH FRAME
DO NOT OVERTIGHTEN
THEN LOOSEN ONE TURN
Location: Chassis Member Behind Transaxles
Part Number: 2351-8
1. Forward Speed Control
• Move lever forward to increase speed; back
to stop.
2. Body Tilt Latch
• Raise lever to release.
• Lift at back of body to raise.
3. Blade Clutch Lever
• Move lever forward to engage PTO clutch;
back to disengage.
2
1.
3.
