Safety Instructions
17
SAFETY, CONTROL, AND INSTRUCTION DECALS
Safety, Control, and Instruction Decals are installed on the machine;
if any are missing, illegible, or damaged, a replacement should be ordered and installed before
putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
Location: Left Fender
Part Number: 2802-3
Location: Front Body Adjacent to
RH Steering Lever
Part Number: 2807-2
1. Low Engine Oil Pressure Warning Light
2. High Oil/Cylinder Head Temperature Light
3. Service Engine Soon Light
1. 2. 3.
Location: Battery Hold-Down Bar
Part Number: 5844-2
IMPORTANT
10% Ethanol maximum
15% MTBE maximum
87 Octane or higher (R+M)/2 (AKI)
90 Octane min (RON)
Fuel Recommendations
5082-5
Location: Rear Body, Left Side
Part Number: 5082-5
1.
2.
1. Throttle
2. Parking brake
• Move lever forward to engage Parking
Brake; back to disengage.
