Walker R21 User Manual

Safety Instructions R21
18
8600-28
1.
2.
Location: Each End of Mower Deck
Part Number: 8600-28
1. Warning – thrown object hazard.
□ Keep bystanders away from the ma-
chine when operating.
□ Clear lawn of debris before operating.
□ Keep any discharge deector in place
and in the lowest position.
2. Warning – rotating mower blades are a cut-
ting/dismemberment hazard to hands and
feet.
□ Keep all body parts away from rotating
mower blades.
□ Do not step on end of deck.
86 0 0 -12
Location: Side of Engine
Part Number: 8600-12
Warning – carbon monoxide (CO) poisoning
hazard.
□ CO emitted by a running engine can be
deadly.
□ Do not operate indoors or in other en-
closed areas.
1.
2.
Location: Seat Panel (Underside)
Part Number: 1600-1
1. Blade Drive Belt routing
2. Ground Drive Belt routing
8
6
0
0
-
5
4
Location: Ignition Switch
Part Number: 8600-54
Ignition switch positions: “O” for OFF, “I” for
ON (RUN), and for START
Location: Chassis Crossmember
in Front of Engine
Part Number: 5855

Walker R21 Specifications

General

Drive System	Hydrostatic
Cutting Height	1.5 - 4.5 inches
Engine	Kohler CH740
Engine Type	Air-cooled
Cutting Width	52 inch
Wheel Size	20 inches (rear)
