Assembly Instructions - Spray Valve SMS-22

Page 24 of 25

Walther Systemtechnik GmbH – D 76726 Germersheim

Telefon: +49 (0)7274-7022-0 Telefax: +49 (0)7274-7022-91

http://www.walther-2000.de – info@walther-2000.de

Figure

Article Number

Description

97320602

Centering sleeve for an exact positioning of the valve

10.6.1 Center hole for Centering sleeve 97320602

WICHTIG

If a Centering sleeve is retrofitted to an existing valve, the valve must be returned to us for

retrofitting of Center hole.
